CKD6E
Fareast
Diesel Locomotive
China Diesel Locomotive list:
Brand | ZIYANG | ZIYANG | ZIYANG |
Diesel Locomotive | CKD9A | CKD6E | SDA4 |
Gauge | 1520mm | 1520mm | 1000mm |
Transmission | AC-DC | AC | |
Axle Arrangement | CO-CO | CO-CO | CO-CO |
Wheel diameter | 1050mm | 1050mm | 1016MM |
axle Load | 23t | 22t | 16t |
Service Weight | 138t | 132t | 96t |
Engine Power | 3680KW | 990KW | 2060kw |
Max speed | 120km/h | 80km/h | 120km/h |
Continuous Speed | 35.5km/h | 9km/h | 19.1km/h |
Max Tractive force | 442kn | 440kn | 380kn |
Tractive force | 292kn | 274kn | 305kn |
Min.Radius of Curvature Negotiated | |||
Fuel tank capacity | |||
Coupler Center Height | |||
Diesel Engine Model | 16V280ZJA | 6240ZJ | CAT3516B |
End user | Tajikistan,Mongolia | Tajikistan | SRT |
Brand | ZIYANG | ZIYANG | ZIYANG |
Diesel Locomotive | SDD8 | SDD2 | CKD7F |
Gauge | 1000mm | 1065mm | 1000mm |
Transmission | AC-DC | ||
Axle Arrangement | CO-CO | CO-CO | CO-CO |
Wheel diameter | 914MM | 914MM | 1000MM |
axle Load | 20t | 18.5t | 13.5t |
Service Weight | 120t | 114t | 81t |
Engine Power | 1960kw | 1620kw | 1455kw |
Max speed | 80km/h | 120km/h | 120km/h |
Continuous Speed | 18km/h | 18.7km/h | 14.7km/h |
Max Tractive force | 384kn | 345kn | 250kn |
Tractive force | 280kn | 223kn | 200kn |
Min.Radius of Curvature Negotiated | |||
Fuel tank capacity | |||
Coupler Center Height | |||
Diesel Engine Model | CAT3516B | CAT3516B | CAT3512B |
End user | Brazil | South Africa | Vietnam |
Brand | ZIYANG | ZIYANG | ZIYANG |
Diesel Locomotive | CK6 | SDD3 | |
Gauge | 1067mm | 1000mm | 1435mm |
Transmission | AC-DC | ||
Axle Arrangement | BO-BO | Co-Co | |
Wheel diameter | 915MM | 1050mm | |
axle Load | 20t | 15t | 18t |
Service Weight | 80t | 60t | 108t |
Engine Power | 977kw | 641kw | 1350kw |
Max speed | 65km/h | 100km/h | 120km/h |
Continuous Speed | 12km/h | 12.2km/h | 12.2km/h |
Max Tractive force | 259kn | 192kn | 346KN |
Tractive force | 224kn | 117kn | 280KN |
Min.Radius of Curvature Negotiated | |||
Fuel tank capacity | |||
Coupler Center Height | |||
Diesel Engine Model | KTA38-L | CAT3412E | CAT3512B |
End user | Zambia,Vietnam | Malaysia | Vietnam |
