WP13B310E200
Weichai
Weichai Engine
Weichai Pump Engine as below:
Weichai Pump Engine List | ||||||||
Weichai WP4 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP4B36E200 | 4 | 105/118 | 4.5 | 36/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E201 | 4 | 105/118 | 4.5 | 36/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E210 | 4 | 105/118 | 4.5 | 36/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E211 | 4 | 105/118 | 4.5 | 36/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E220 | 4 | 105/118 | 4.5 | 36/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E221 | 4 | 105/118 | 4.5 | 36/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E200 | 4 | 105/118 | 4.5 | 50/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E201 | 4 | 105/118 | 4.5 | 50/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E210 | 4 | 105/118 | 4.5 | 50/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E211 | 4 | 105/118 | 4.5 | 50/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E220 | 4 | 105/118 | 4.5 | 50/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E221 | 4 | 105/118 | 4.5 | 50/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E200 | 4 | 105/118 | 4.5 | 70/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E201 | 4 | 105/118 | 4.5 | 70/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E210 | 4 | 105/118 | 4.5 | 70/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E211 | 4 | 105/118 | 4.5 | 70/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E220 | 4 | 105/118 | 4.5 | 70/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E221 | 4 | 105/118 | 4.5 | 70/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E200 | 4 | 105/118 | 4.5 | 90/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E201 | 4 | 105/118 | 4.5 | 90/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E210 | 4 | 105/118 | 4.5 | 90/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E211 | 4 | 105/118 | 4.5 | 90/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E220 | 4 | 105/118 | 4.5 | 90/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E221 | 4 | 105/118 | 4.5 | 90/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B105E201 | 4 | 105/118 | 4.5 | 105/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B105E221 | 4 | 105/118 | 4.5 | 105/1800 | Pump | 950*660*780 | 420 |
Weichai WP6 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP6B120E200 | 6 | 105/130 | 6.75 | 120/1500 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E201 | 6 | 105/130 | 6.75 | 120/1800 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E210 | 6 | 105/130 | 6.75 | 120/1500 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E211 | 6 | 105/130 | 6.75 | 120/1800 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E220 | 6 | 105/130 | 6.75 | 120/1500 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E221 | 6 | 105/130 | 6.75 | 120/1800 | Pump | 1178*640*919 | 636 |
Weichai | WP6B144E201 | 6 | 105/130 | 6.75 | 144/1800 | Pump | 1178*640*919 | 636 |
Weichai | WP6B144E221 | 6 | 105/130 | 6.75 | 144/1800 | Pump | 1178*640*919 | 636 |
Weichai WP10 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP10B150E200 | 6 | 126*130 | 9.7 | 150/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E201 | 6 | 126*130 | 9.7 | 150/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E210 | 6 | 126*130 | 9.7 | 150/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E211 | 6 | 126*130 | 9.7 | 150/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E220 | 6 | 126*130 | 9.7 | 150/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E221 | 6 | 126*130 | 9.7 | 150/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E230 | 6 | 126*130 | 9.7 | 150/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E231 | 6 | 126*130 | 9.7 | 150/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E200 | 6 | 126*130 | 9.7 | 190/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E201 | 6 | 126*130 | 9.7 | 190/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E210 | 6 | 126*130 | 9.7 | 190/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E211 | 6 | 126*130 | 9.7 | 190/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E220 | 6 | 126*130 | 9.7 | 190/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E221 | 6 | 126*130 | 9.7 | 190/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E230 | 6 | 126*130 | 9.7 | 190/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E231 | 6 | 126*130 | 9.7 | 190/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E200 | 6 | 126*130 | 9.7 | 216/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E201 | 6 | 126*130 | 9.7 | 216/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E210 | 6 | 126*130 | 9.7 | 216/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E211 | 6 | 126*130 | 9.7 | 216/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E220 | 6 | 126*130 | 9.7 | 216/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E221 | 6 | 126*130 | 9.7 | 216/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E230 | 6 | 126*130 | 9.7 | 216/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E231 | 6 | 126*130 | 9.7 | 216/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E200 | 6 | 126*130 | 9.7 | 240/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E201 | 6 | 126*130 | 9.7 | 240/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E210 | 6 | 126*130 | 9.7 | 240/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E211 | 6 | 126*130 | 9.7 | 240/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E220 | 6 | 126*130 | 9.7 | 240/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E221 | 6 | 126*130 | 9.7 | 240/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E230 | 6 | 126*130 | 9.7 | 240/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E231 | 6 | 126*130 | 9.7 | 240/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B255E201 | 6 | 126*130 | 9.7 | 255/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B255E221 | 6 | 126*130 | 9.7 | 255/1800 | Pump | 1772*870*1170 | 875 |
Weichai WP12 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP12B288E200 | 6 | 126*155 | 11.59 | 288/1500 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E201 | 6 | 126*155 | 11.59 | 288/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E210 | 6 | 126*155 | 11.59 | 288/1500 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E211 | 6 | 126*155 | 11.59 | 288/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E220 | 6 | 126*155 | 11.59 | 288/1500 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E221 | 6 | 126*155 | 11.59 | 288/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E230 | 6 | 126*155 | 11.59 | 288/1500 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E231 | 6 | 126*155 | 11.59 | 288/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B335E201 | 6 | 126*155 | 11.59 | 335/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B335E211 | 6 | 126*155 | 11.59 | 335/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B335E221 | 6 | 126*155 | 11.59 | 335/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B335E231 | 6 | 126*155 | 11.59 | 335/1800 | Pump | 1761*847*1309 | 1050 |
Weichai WP13 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP13B310E200 | 6 | 127*165 | 12.54 | 310/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B310E210 | 6 | 127*165 | 12.54 | 310/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B310E220 | 6 | 127*165 | 12.54 | 310/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B310E230 | 6 | 127*165 | 12.54 | 310/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E200 | 6 | 127*165 | 12.54 | 350/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E201 | 6 | 127*165 | 12.54 | 350/1800 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E210 | 6 | 127*165 | 12.54 | 350/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E211 | 6 | 127*165 | 12.54 | 350/1800 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E220 | 6 | 127*165 | 12.54 | 350/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E221 | 6 | 127*165 | 12.54 | 350/1800 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E230 | 6 | 127*165 | 12.54 | 350/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E231 | 6 | 127*165 | 12.54 | 350/1800 | Pump | 1813*954*1289 | 1050 |
Weichai Baudouin M26 and M33 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | 6M26B440E200 | 6 | 150*150 | 15.9 | 440/1500 | Pump | 2260*1224*1551 | 1900 |
Weichai | 6M26B440E201 | 6 | 150*150 | 15.9 | 440/1800 | Pump | 2260*1224*1551 | 1900 |
Weichai | 6M26B440E210 | 6 | 150*150 | 15.9 | 440/1500 | Pump | 2260*1224*1551 | 1900 |
Weichai | 6M26B440E211 | 6 | 150*150 | 15.9 | 440/1800 | Pump | 2260*1224*1551 | 1900 |
Weichai | 12M26B880E200 | 12 | 150*150 | 31.8 | 880/1500 | Pump | 3203*1992*2344 | 3200 |
Weichai | 12M26B880E201 | 12 | 150*150 | 31.8 | 880/1800 | Pump | 3203*1992*2344 | 3200 |
Weichai | 12M26B880E210 | 12 | 150*150 | 31.8 | 880/1500 | Pump | 3203*1992*2344 | 3200 |
Weichai | 12M26B880E211 | 12 | 150*150 | 31.8 | 880/1800 | Pump | 3203*1992*2344 | 3200 |
Weichai | 12M33B1000E200 | 12 | 150*185 | 39.8 | 1000/1800 | Pump | 2524*1311*1731 | 3390 |
Manufactured by China Weichai, Weichai Pump engine
Weichai engine model Compilation Rules,example :
WP13B310E200 | |
WP | Weichai power |
13 | 13 series |
B | General purpose or Pump or Stationary power |
310 | 310HP |
E2 | Euro 2 Emission |
| 00 | Application |
Weichai engine application:
SN | Symbol | Application |
1 | B | General purpose or Pump or Stationary power |
2 | C | Marine main propulsion engine |
3 | G | Construction machinery |
4 | Q | Truck |
5 | D | Land generator |
6 | CD | Marine auxiliary engine |
7 | K | Coach |
8 | T | Tractor |
9 | Other |
Not only supply above engine, also can supply:
Brand | Model | Application |
Weichai | WP2.1 Series | Automotive,Construction machinery |
Weichai | WP3 Series | Automotive,Construction machinery |
Weichai | WP3.7 Series | Automotive |
Weichai | WP4.1 Series | Automotive,Marine,Generator,Harvester |
Weichai | WP4 Series | Automotive,Marine,Generator,Pump,Air compressor,Tractor,Harvester |
Weichai | WP5 Series | Automotive |
Weichai | WP6 Series | Automotive,Construction machinery,Marine,Generator |
Weichai | WP6 Series | Pump,Air compressor,Tractor,Harvester |
Weichai | WP7 Series | Automotive,Marine |
Weichai | WD10 Series | Marine |
Weichai | WP10 Series | Automotive,Construction machinery,Marine,Generator,Pump |
Weichai | WP10 Series | Air compressor,Ensiling machine |
Weichai | WD12 Series | Marine,Generator |
Weichai | WP12 Series | Automotive,Construction machinery,Pump,Air compressor,Ensiling machine |
Weichai | WP12L Series | Construction machinery |
Weichai | WP13 Series | Construction machinery,Generator,Pump,Air compressor |
Weichai | WP5NG Series | Gas Engine |
Weichai | WP6NG Series | Gas Engine |
Weichai | WP7NG Series | Gas Engine |
Weichai | WP10NG Series | Gas Engine |
Weichai | WP12NG Series | Gas Engine |
Weichai | CW200 Series | Chongqing Weichai Marine Engine |
Weichai | CW250 Series | Chongqing Weichai Marine Engine |
Weichai | WHM6160 Series | Weichai Heavy Machinery Marine Engine |
Weichai | X170ZC Series | Weichai Heavy Machinery Marine Engine |
Beside engine,also can supply above engine spare parts
SN | Parts Descriptions |
1 | cylinder head, cylinder block, cylinder liner,crankshaft,camshaft |
2 | piston, piston ring, piston pin,conrod,flywheel,flywheel housing,exhaust |
3 | main bearing, conrod bearing, thrust bearing |
4 | fuel injector, fuel injection pump, common rail |
5 | oil pan gasket, cylinder head gasket |
6 | overhaul gasket kit, upper gasket kit, lower gasket kit |
7 | intake valve,exhuast valve,valve seat,valve rotating |
8 | fuel transfer pump, water pump, oil pump, vacuum pump, power steering |
9 | oil filter, fuel filter, fuel water separator, air filter |
10 | turbocharger,alternator,starter,air compressor |
11 | other spare parts |
Beside engine, other brand engine and spare parts also available,such as:
SN | Brand | Engine or Spare parts |
1 | Deutz | Engine and spare parts |
2 | Googol | Engine and spare parts |
3 | Baudouin | Engine and spare parts |
4 | Doosan | Engine and spare parts |
5 | MAN | Engine and spare parts |
6 | Iveco | Engine and spare parts |
7 | Isuzu | Engine and spare parts |
8 | Toyota | Engine and spare parts |
9 | Nissan | Engine and spare parts |
10 | Shangchai | Engine and spare parts |
11 | Weichai | Engine and spare parts |
12 | Yuchai | Engine and spare parts |
13 | Sinotruk | Engine and spare parts |
14 | Fada | Gearbox |
15 | Advance | Gearbox |
16 | ABB | Turbocharger |
17 | MAN | Turbocharger |
18 | EMD | Spare parts |
19 | GE | Spare parts |
20 | ALCO | Spare parts |
21 | MAN | Spare parts |
22 | MTU | Spare parts |
23 | Pielstick | Spare parts |
24 | DAIHATSU | Spare parts |
25 | MAK | Spare parts |
26 | SULZER | Spare parts |
27 | WARTSILA | Spare parts |
28 | SKL | Spare parts |
29 | RUSTON | Spare parts |
30 | YANMAR | Spare parts |
31 | AKASAKA | Spare parts |
32 | HANSHIN | Spare parts |
33 | NlIGATA | Spare parts |
Weichai Pump Engine as below:
Weichai Pump Engine List | ||||||||
Weichai WP4 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP4B36E200 | 4 | 105/118 | 4.5 | 36/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E201 | 4 | 105/118 | 4.5 | 36/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E210 | 4 | 105/118 | 4.5 | 36/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E211 | 4 | 105/118 | 4.5 | 36/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E220 | 4 | 105/118 | 4.5 | 36/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B36E221 | 4 | 105/118 | 4.5 | 36/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E200 | 4 | 105/118 | 4.5 | 50/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E201 | 4 | 105/118 | 4.5 | 50/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E210 | 4 | 105/118 | 4.5 | 50/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E211 | 4 | 105/118 | 4.5 | 50/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E220 | 4 | 105/118 | 4.5 | 50/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B50E221 | 4 | 105/118 | 4.5 | 50/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E200 | 4 | 105/118 | 4.5 | 70/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E201 | 4 | 105/118 | 4.5 | 70/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E210 | 4 | 105/118 | 4.5 | 70/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E211 | 4 | 105/118 | 4.5 | 70/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E220 | 4 | 105/118 | 4.5 | 70/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B70E221 | 4 | 105/118 | 4.5 | 70/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E200 | 4 | 105/118 | 4.5 | 90/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E201 | 4 | 105/118 | 4.5 | 90/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E210 | 4 | 105/118 | 4.5 | 90/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E211 | 4 | 105/118 | 4.5 | 90/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E220 | 4 | 105/118 | 4.5 | 90/1500 | Pump | 950*660*780 | 420 |
Weichai | WP4B90E221 | 4 | 105/118 | 4.5 | 90/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B105E201 | 4 | 105/118 | 4.5 | 105/1800 | Pump | 950*660*780 | 420 |
Weichai | WP4B105E221 | 4 | 105/118 | 4.5 | 105/1800 | Pump | 950*660*780 | 420 |
Weichai WP6 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP6B120E200 | 6 | 105/130 | 6.75 | 120/1500 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E201 | 6 | 105/130 | 6.75 | 120/1800 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E210 | 6 | 105/130 | 6.75 | 120/1500 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E211 | 6 | 105/130 | 6.75 | 120/1800 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E220 | 6 | 105/130 | 6.75 | 120/1500 | Pump | 1178*640*919 | 636 |
Weichai | WP6B120E221 | 6 | 105/130 | 6.75 | 120/1800 | Pump | 1178*640*919 | 636 |
Weichai | WP6B144E201 | 6 | 105/130 | 6.75 | 144/1800 | Pump | 1178*640*919 | 636 |
Weichai | WP6B144E221 | 6 | 105/130 | 6.75 | 144/1800 | Pump | 1178*640*919 | 636 |
Weichai WP10 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP10B150E200 | 6 | 126*130 | 9.7 | 150/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E201 | 6 | 126*130 | 9.7 | 150/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E210 | 6 | 126*130 | 9.7 | 150/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E211 | 6 | 126*130 | 9.7 | 150/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E220 | 6 | 126*130 | 9.7 | 150/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E221 | 6 | 126*130 | 9.7 | 150/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E230 | 6 | 126*130 | 9.7 | 150/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B150E231 | 6 | 126*130 | 9.7 | 150/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E200 | 6 | 126*130 | 9.7 | 190/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E201 | 6 | 126*130 | 9.7 | 190/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E210 | 6 | 126*130 | 9.7 | 190/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E211 | 6 | 126*130 | 9.7 | 190/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E220 | 6 | 126*130 | 9.7 | 190/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E221 | 6 | 126*130 | 9.7 | 190/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E230 | 6 | 126*130 | 9.7 | 190/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B190E231 | 6 | 126*130 | 9.7 | 190/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E200 | 6 | 126*130 | 9.7 | 216/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E201 | 6 | 126*130 | 9.7 | 216/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E210 | 6 | 126*130 | 9.7 | 216/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E211 | 6 | 126*130 | 9.7 | 216/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E220 | 6 | 126*130 | 9.7 | 216/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E221 | 6 | 126*130 | 9.7 | 216/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E230 | 6 | 126*130 | 9.7 | 216/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B216E231 | 6 | 126*130 | 9.7 | 216/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E200 | 6 | 126*130 | 9.7 | 240/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E201 | 6 | 126*130 | 9.7 | 240/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E210 | 6 | 126*130 | 9.7 | 240/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E211 | 6 | 126*130 | 9.7 | 240/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E220 | 6 | 126*130 | 9.7 | 240/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E221 | 6 | 126*130 | 9.7 | 240/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E230 | 6 | 126*130 | 9.7 | 240/1500 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B240E231 | 6 | 126*130 | 9.7 | 240/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B255E201 | 6 | 126*130 | 9.7 | 255/1800 | Pump | 1772*870*1170 | 875 |
Weichai | WP10B255E221 | 6 | 126*130 | 9.7 | 255/1800 | Pump | 1772*870*1170 | 875 |
Weichai WP12 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP12B288E200 | 6 | 126*155 | 11.59 | 288/1500 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E201 | 6 | 126*155 | 11.59 | 288/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E210 | 6 | 126*155 | 11.59 | 288/1500 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E211 | 6 | 126*155 | 11.59 | 288/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E220 | 6 | 126*155 | 11.59 | 288/1500 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E221 | 6 | 126*155 | 11.59 | 288/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E230 | 6 | 126*155 | 11.59 | 288/1500 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B288E231 | 6 | 126*155 | 11.59 | 288/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B335E201 | 6 | 126*155 | 11.59 | 335/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B335E211 | 6 | 126*155 | 11.59 | 335/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B335E221 | 6 | 126*155 | 11.59 | 335/1800 | Pump | 1761*847*1309 | 1050 |
Weichai | WP12B335E231 | 6 | 126*155 | 11.59 | 335/1800 | Pump | 1761*847*1309 | 1050 |
Weichai WP13 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | WP13B310E200 | 6 | 127*165 | 12.54 | 310/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B310E210 | 6 | 127*165 | 12.54 | 310/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B310E220 | 6 | 127*165 | 12.54 | 310/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B310E230 | 6 | 127*165 | 12.54 | 310/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E200 | 6 | 127*165 | 12.54 | 350/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E201 | 6 | 127*165 | 12.54 | 350/1800 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E210 | 6 | 127*165 | 12.54 | 350/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E211 | 6 | 127*165 | 12.54 | 350/1800 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E220 | 6 | 127*165 | 12.54 | 350/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E221 | 6 | 127*165 | 12.54 | 350/1800 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E230 | 6 | 127*165 | 12.54 | 350/1500 | Pump | 1813*954*1289 | 1050 |
Weichai | WP13B350E231 | 6 | 127*165 | 12.54 | 350/1800 | Pump | 1813*954*1289 | 1050 |
Weichai Baudouin M26 and M33 Series Pump engine | ||||||||
Brand | Model | Cyl | Bore/Stroke | Liter | KW/RPM | Application | Dimension | Weight |
Weichai | 6M26B440E200 | 6 | 150*150 | 15.9 | 440/1500 | Pump | 2260*1224*1551 | 1900 |
Weichai | 6M26B440E201 | 6 | 150*150 | 15.9 | 440/1800 | Pump | 2260*1224*1551 | 1900 |
Weichai | 6M26B440E210 | 6 | 150*150 | 15.9 | 440/1500 | Pump | 2260*1224*1551 | 1900 |
Weichai | 6M26B440E211 | 6 | 150*150 | 15.9 | 440/1800 | Pump | 2260*1224*1551 | 1900 |
Weichai | 12M26B880E200 | 12 | 150*150 | 31.8 | 880/1500 | Pump | 3203*1992*2344 | 3200 |
Weichai | 12M26B880E201 | 12 | 150*150 | 31.8 | 880/1800 | Pump | 3203*1992*2344 | 3200 |
Weichai | 12M26B880E210 | 12 | 150*150 | 31.8 | 880/1500 | Pump | 3203*1992*2344 | 3200 |
Weichai | 12M26B880E211 | 12 | 150*150 | 31.8 | 880/1800 | Pump | 3203*1992*2344 | 3200 |
Weichai | 12M33B1000E200 | 12 | 150*185 | 39.8 | 1000/1800 | Pump | 2524*1311*1731 | 3390 |
Manufactured by China Weichai, Weichai Pump engine
Weichai engine model Compilation Rules,example :
WP13B310E200 | |
WP | Weichai power |
13 | 13 series |
B | General purpose or Pump or Stationary power |
310 | 310HP |
E2 | Euro 2 Emission |
| 00 | Application |
Weichai engine application:
SN | Symbol | Application |
1 | B | General purpose or Pump or Stationary power |
2 | C | Marine main propulsion engine |
3 | G | Construction machinery |
4 | Q | Truck |
5 | D | Land generator |
6 | CD | Marine auxiliary engine |
7 | K | Coach |
8 | T | Tractor |
9 | Other |
Not only supply above engine, also can supply:
Brand | Model | Application |
Weichai | WP2.1 Series | Automotive,Construction machinery |
Weichai | WP3 Series | Automotive,Construction machinery |
Weichai | WP3.7 Series | Automotive |
Weichai | WP4.1 Series | Automotive,Marine,Generator,Harvester |
Weichai | WP4 Series | Automotive,Marine,Generator,Pump,Air compressor,Tractor,Harvester |
Weichai | WP5 Series | Automotive |
Weichai | WP6 Series | Automotive,Construction machinery,Marine,Generator |
Weichai | WP6 Series | Pump,Air compressor,Tractor,Harvester |
Weichai | WP7 Series | Automotive,Marine |
Weichai | WD10 Series | Marine |
Weichai | WP10 Series | Automotive,Construction machinery,Marine,Generator,Pump |
Weichai | WP10 Series | Air compressor,Ensiling machine |
Weichai | WD12 Series | Marine,Generator |
Weichai | WP12 Series | Automotive,Construction machinery,Pump,Air compressor,Ensiling machine |
Weichai | WP12L Series | Construction machinery |
Weichai | WP13 Series | Construction machinery,Generator,Pump,Air compressor |
Weichai | WP5NG Series | Gas Engine |
Weichai | WP6NG Series | Gas Engine |
Weichai | WP7NG Series | Gas Engine |
Weichai | WP10NG Series | Gas Engine |
Weichai | WP12NG Series | Gas Engine |
Weichai | CW200 Series | Chongqing Weichai Marine Engine |
Weichai | CW250 Series | Chongqing Weichai Marine Engine |
Weichai | WHM6160 Series | Weichai Heavy Machinery Marine Engine |
Weichai | X170ZC Series | Weichai Heavy Machinery Marine Engine |
Beside engine,also can supply above engine spare parts
SN | Parts Descriptions |
1 | cylinder head, cylinder block, cylinder liner,crankshaft,camshaft |
2 | piston, piston ring, piston pin,conrod,flywheel,flywheel housing,exhaust |
3 | main bearing, conrod bearing, thrust bearing |
4 | fuel injector, fuel injection pump, common rail |
5 | oil pan gasket, cylinder head gasket |
6 | overhaul gasket kit, upper gasket kit, lower gasket kit |
7 | intake valve,exhuast valve,valve seat,valve rotating |
8 | fuel transfer pump, water pump, oil pump, vacuum pump, power steering |
9 | oil filter, fuel filter, fuel water separator, air filter |
10 | turbocharger,alternator,starter,air compressor |
11 | other spare parts |
Beside engine, other brand engine and spare parts also available,such as:
SN | Brand | Engine or Spare parts |
1 | Deutz | Engine and spare parts |
2 | Googol | Engine and spare parts |
3 | Baudouin | Engine and spare parts |
4 | Doosan | Engine and spare parts |
5 | MAN | Engine and spare parts |
6 | Iveco | Engine and spare parts |
7 | Isuzu | Engine and spare parts |
8 | Toyota | Engine and spare parts |
9 | Nissan | Engine and spare parts |
10 | Shangchai | Engine and spare parts |
11 | Weichai | Engine and spare parts |
12 | Yuchai | Engine and spare parts |
13 | Sinotruk | Engine and spare parts |
14 | Fada | Gearbox |
15 | Advance | Gearbox |
16 | ABB | Turbocharger |
17 | MAN | Turbocharger |
18 | EMD | Spare parts |
19 | GE | Spare parts |
20 | ALCO | Spare parts |
21 | MAN | Spare parts |
22 | MTU | Spare parts |
23 | Pielstick | Spare parts |
24 | DAIHATSU | Spare parts |
25 | MAK | Spare parts |
26 | SULZER | Spare parts |
27 | WARTSILA | Spare parts |
28 | SKL | Spare parts |
29 | RUSTON | Spare parts |
30 | YANMAR | Spare parts |
31 | AKASAKA | Spare parts |
32 | HANSHIN | Spare parts |
33 | NlIGATA | Spare parts |
